Company Advantages

· modern outdoor lighting is elaborately designed by innovative experts who know well about the market changing demands.

· Regular performance checks have been implemented to ensure the high performance and reliable quality of the product.

· Fast delivery methods enable Shanghai Jing Rui Lighting Co., Ltd. to gain a reputation in the domestic and international markets.

Our advantage

● Professional cooling structure technology, inside and outside air ducts design, high efficiency heat dissipation performance.

● IP67 protection level, LED module has IP68 protection level.

● A variety of lens options to meet different application requirements for light distribution, optical PC lens, uniform glare-free brightness.

● Freely assembled different numbers of modules for different power, highly adaptable functionality.

● All-metal structure, high mechanical strength.

● Suitable for factories, industrial sites, sports field, gas stations, parking lots, station halls, railway stations, ports installations and mobile light towers etc.

Product details

Thermal honeycomb

Thermal honeycomb effect heat dissipation, effectively ensure the service life of the lamp

Full structure heat dissipation

Full structure heat dissipation, effectively reduce the temperature of the radiator, extend the service life of the light source.

IP68

Dual-coupled IP68 protection of chip modules

High efficiency LED light source

High efficiency LED light source to ensure the high efficiency of the whole lamp

Modular combination design

Modular combination design, to meet different power requirements of the combination, easy maintenance, reduce maintenance costs.

Anti-shock and anti-fall design

Anti-shock and anti-fall design, the fixing hook angle is matched with the orbital groove of the lamp body material. Even if the screws are loose under the vibration, the lamp body will not fall off.

Arch bridge structure design

Arch bridge structure design, to meet the harsh conditions of use in vibration places.

180° adjustment angle design

180° adjustment angle design to meet the requirements of different irradiation directions.

A variery of lens options

A variery of lens options to meet different application requirements for light distribution.

Company Features

· With years of experience in developing, designing, and manufacturing modern outdoor lighting, we are positioned as a reliable developer, manufacturer, and supplier.

· With our well-developed market system all around the world, we have built a solid customer base and meanwhile are widely recognized by our customers throughout efforts.

· We have corporated with our customers to realize their sustainability goals in a safe, energy-efficient, and environmentally conscious manner.

Product Details

Jing Rui produces modern outdoor lighting according to national standards, and the products are of good quality. The specific details are as follows.

Application of the Product

Jing Rui's modern outdoor lighting can meet the different needs of customers.

Based on the actual needs of our customers, we provide a one-stop solution for them with the purpose of rational allocation of Metal Halide Flood Lights,LED Flood Lights,LED High Bay Lights,LED Street Lights,LED Work Lights,Grow Lights,Light Bulbs.

Product parameters

Model

Power(W)

Module Qty

Light Efficiency

Voltage(V)

CRI(Ra)

Beam Angle

CCT(K)

Power Factor

N.W/G.W
(KG)

Packing size
(mm)

JR309-50W

190Lm/W

AC100-277V
DC24V
DC48V

≥70

25°
40°
60°
90°
110°

3000~6000

-40~50℃

＞0.95

2.7/3.2

395×210×200

JR309-100W

100

190Lm/W

4.0/4.5

395×250×200

JR309-150W

150

170Lm/W

4.0/4.5

395×250×200

JR309-200W

200

180Lm/W

5.5/6.2

395×350×200

JR309-240W

240

170Lm/W

5.5/6.2

395×350×200

JR309-300W

300

170Lm/W

8.8/10.0

485×390×210

JR309-350W

350

180Lm/W

11.2/12.2

540×390×235

JR309-400W

400

180Lm/W

11.2/12.2

540×390×235

JR309-480W

480

170Lm/W

11.2/12.2

540×390×235

JR309-500W

500

180Lm/W

14.6/16.1

700×390×235

JR309-600W

600

170Lm/W

14.6/16.1

700×390×235

Note: Letter "W" in the model no. stands for AC voltage; "DT" stands for DC24V; "DF" stands for DC48V.

Product size

Size/Model	a	b	c	d
JR309-50W	296	80	130	150
JR309-100W	296	160	154	210
JR309-150W	296	240	154	290
JR309-200W	296	240	154	290
JR309-240W	320	320	165	346
JR309-300W	320	320	165	346
JR309-350W	480	296	165	346
JR309-400W	480	296	165	346
JR309-480W	480	296	165	346
JR309-500W	640	296	165	346
JR309-600W	640	296	165	346

Product photometrics

25°

40°

60°

90°

110°

Application Scenarios

Light Tower

Port Terminal

Stadium

High Pole Light

FAQ

What is the voltage range of your LED flood light?

We offer a voltage range of AC100~277V and DC12V/DC24V/DC48V.

How do your products compare to similar products in the market?

Our products are highly efficient, lightweight, anti-corrosive, and anti-shock performance.

What certifications have you obtained?

Our LED Lights are CSA, SAA, CE, and BIS-approved.

What’s the application for your LED flood Light?

Our LED flood lights are widely used at Diesel/Solar/Hybrid lighting towers, stadiums, Sports fields, Ports, Industrial places, Construction Sites, Docks, Mining Sites etc.

What’s the luminous efficiency of your LED Flood Light?

Our LED Flood light offers 150~200lm/w.

Do you offer a guarantee for the products?

Yes, We offer a 2-year warranty for DC LED lights and a 3-year warranty for DC LED lights.

Can your factory make the lights based on customers' designs?

Yes, we offer OEM and ODM service, we can design and produce according to the client's requests, and we have professional engineers for R&D.

Are you a factory or trading company?

We are a factory and trading company integration. our sales center and R&D department are located in Shanghai, and the factory is located in Suzhou City. We welcome customers to visit our factory.
