Brand Modern Outdoor Lighting Supplier
Our advantage
● Adopts the modular design with efficient thermal conduction,radiation and convection.
● Variety of lens options can meet the light distribution requirements of different application environments. Optical grade PC material lens has uniform light output and no glare.
● The mounting bracket can arbitrarily adjust the illumination angle of the light，fixed with high strength locknut.
● Global wide voltage operation, conform to various general standards, easy to replace directly.
● Durable, long service life, up to 50000 hours, no need to change lamps frequently.
● Suitable used for industrial place, stadium, parking lots, ports, docks, mobile light tower, mines, coal plants, etc.
Product details
Company Advantages
· modern outdoor lighting is designed with a trendy and aesthetically-appealing look.
· Our experienced quality inspectors have carefully tested the product in all respects, such as its performance, durability, and so on, in accordance with the international standards.
· Shanghai Jing Rui Lighting Co., Ltd. works hard to achieve a win-win situation with customers.
Company Features
· Shanghai Jing Rui Lighting Co., Ltd. is an enterprise specialized in modern outdoor lighting, which owns a leading technical team from this trade.
· We not only have our product throughout the country but also exported to Europe, America, Southeast Asia, and so forth. We have also finished several projects with some world-famous brands.
· Always following the market trends, the company aims at providing customers and potential consumers with all-around services such as custom-made products. Inquire now!
Application of the Product
modern outdoor lighting developed and produced by Jing Rui is widely applied to many industries and fields. It can fully meet the diversified needs of customers.
Jing Rui has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.
Product parameters
| Model | Power(W) | Module Qty | Light Efficiency | Voltage(V) | CRI(Ra) | Power Factor | Beam Angle | CCT(K) | Ta | N.W/G.W (KG) |
Packing size (mm) |
| JR319-50W | 50 | 1 | 190Lm/W | AC100~277V DC24V DC48V |
≥70 | ＞0.95 | 25° 40° 60° 90° |
3000~6000 | -40℃~50℃ | 2.8/3.3 | 190×415×175 |
| JR319-100W | 100 | 2 | 190Lm/W | 3.7/4.2 | 250×415×175 | ||||||
| JR319-150W | 150 | February 3rd | 170Lm/W | 3.8/4.3 | 250×415×175 | ||||||
| JR319-200W | 200 | 3 | 180Lm/W | 4.8/5.4 | 325×415×175 | ||||||
| JR319-240W | 240 | 4 | 180Lm/W | 6.3/7.2 | 400×415×175 | ||||||
| JR319-320W | 320 | 4 | 170Lm/W | 6.8/7.7 | 400×415×175 | ||||||
| JR319-350W | 350 | 5 | 180Lm/W | 7.8/8.8 | 480×415×175 | ||||||
| JR319-400W | 400 | May 6th | 170Lm/W | 8.1/9.1 | 480×415×175 | ||||||
| JR319-480W | 480 | 6 | 170Lm/W | 10.1/11.2 | 560×415×175 | ||||||
| Note: Letter "W" in the model no. stands for AC voltage; "DT" stands for DC24V; "DF" stands for DC48V. | |||||||||||
Product size
| Size/Model | a | b | c |
| JR319-50W | 380 | 150 | 105 |
| JR319-100W | 380 | 216 | 105 |
| JR319-150W | 380 | 216 | 107 |
| JR319-200W | 380 | 295 | 115 |
| JR319-240W | 380 | 373 | 115 |
| JR319-320W | 380 | 373 | 115 |
| JR319-350W | 380 | 450 | 115 |
| JR319-400W | 380 | 450 | 115 |
| JR319-480W | 380 | 530 | 115 |
Application Scenarios
